Environment |
|
Power consumption |
326.5W, 1114.01BTU/hr (idle)
512.2W, 1747.62BTU/hr (full load)
|
Operating temperature |
0-40°C (operating)
-40 to +70°C (storage)
|
Humidity | 5%-90%, non-condensing |
Product Certifications |
|
Certifications |
CE, UL, FCC, ISED, CCC,
VCCI, RCM, BIS (CRS)
|
Performance |
|
Firewall throughput | 100 Gbps |
Firewall IMIX | 33.5 Gbps |
VPN throughput | 11 Gbps |
IPS throughput | 22 Gbps |
NGFW (IPS + App Ctrl + WebFilter) max. |
11.8 Gbps |
Antivirus throughput (proxy) | 17 Gbps |
Concurrent connections | 30,000,000 |
New connections/sec | 300,000 |
Maximum licensed users | unrestricted |
Physical interfaces |
|
Storage (local
quarantine/logs)
|
2 x integrated hot-swap SSD (RAID) |
Ethernet interfaces
(removable)
|
8 GE copper |
No. of FleXi Port slots | 8 |
FleXi Port modules (optional) |
8 port GE copper
8 port GE SFP*
2 port 10 GE SFP+*
4 port 10 GE SFP+*
4 port SFP*
plus 4 port GE
copper LAN bypass
|
I/O ports |
2 x USB 2.0 (front)
1 x USB 3.0 (rear)
2 x Mgmt Port (eth0/eth1, front)
1 x COM (RJ45) (front)
1 x VGA (rear)
|
Display | Multi-function LCD module |
Power supply |
2 x hot-swap external auto-
ranging 100-240VAC, 50-60 Hz
|
Physical specifications |
|
Mounting | 2U sliding rails (included) |
Dimensions
Width x Depth x Height
|
438 x 600 x 88 mm
17.24 x 23.62 x 3.46 inches
|
Weight |
17.8 kg / 39.24 lbs (unpacked)
27 kg / 59.53 lbs (packed)
|
