Environment |
|
Power consumption |
3.24W, 11.04 BTU/h (idle)
5.64W, 19.232 BTU/h (full load)
|
Operating temperature |
0-40°C (operating)
-20 to +80°C (storage)
|
Humidity | 10%-90%, non-condensing |
Product Certifications |
|
Certifications |
CB, CE, FCC Class B, IC, VCCI,
MIC, RCM, UL, CCC
|
Performance |
|
Firewall throughput | 2 Gbps |
Firewall IMIX | 780 Mbps |
VPN throughput | 200 Mbps |
IPS throughput | 510 Mbps |
NGFW (IPS + App Ctrl + WebFilter) max. |
235 Mbps |
Antivirus throughput (proxy) | 330 Mbps |
Concurrent connections | 2,000,000 |
New connections/sec | 18,000 |
Maximum licensed users | unrestricted |
Wireless Specification |
|
No. of antennas | 2 external |
MIMO capabilities | 2 x 2:2 |
Wireless interface | 802.11a/b/g/n (2.4 GHz / 5 GHz) |
Physical interfaces |
|
Storage (local
quarantine/logs)
|
8 GB eMMC |
Ethernet interfaces
(fixed)
|
4 GE copper |
I/0 Ports (rear) |
2 x USB 2.0
1 x COM (RJ45)
|
Power Supply |
External auto ranging DC: 12V,
100-240VAC, 50-60 Hz
|
Physical specifications |
|
Mounting |
Rackmount kit available
(to be ordered separately)
|
Dimensions
Width x Depth x Height
|
225 x 150 x 44 mm
8.86 x 5.91 x 1.73 inches
|
Weight |
0.95 kg / 2.09 lbs (unpacked)
1.97 kg / 4.34 lbs (packed)
|
