Environment |
|
Power consumption |
XG 430: 36W, 123 BTU/hr (idle)
147W, 502 BTU/hr (full load)
XG 450: 53W, 181 BTU/hr (idle)
163W, 556 BTU/hr (full load)
|
Operating temperature |
0-40°C (operating)
-20 to + 70°C (storage)
|
Humidity | 0%-90%, non-condensing |
Product Certifications |
|
Certifications |
CB, CE, FCC Class A, IC,
VCCI, RCM, UL, CCC
|
Performance |
|
Firewall throughput | 45 Gbps |
Firewall IMIX | 15.65 Gbps |
VPN throughput | 5.5 Gbps |
IPS throughput | 10 Gbps |
NGFW (IPS + App Ctrl + WebFilter) max. |
5 Gbps |
Antivirus throughput (proxy) | 7 Gbps |
Concurrent connections | 20,000,000 |
New connections/sec | 200,000 |
Maximum licensed users | unrestricted |
Physical interfaces |
|
Storage (local
quarantine/logs)
|
2 x integrated SSD |
Ethernet interfaces
(removable)
|
8 GE copper |
No. of FleXi Port slots | 3 |
FleXi Port modules (optional) |
8 port GE copper
8 port GE SFP*
2 port 10 GE SFP+*
4 port 10 GE SFP+*
4 port GE copper
LAN bypass
|
I/O ports |
2 x USB 3.0 (front)
1 x USB 3.0 (rear)
1 x COM (RJ45)
(front)
1 x VGA (rear)
|
Display |
Multi-function
LCD module
|
Power supply |
Internal auto-
ranging
100-
240VAC, 50-60 Hz
|
Physical specifications |
|
Mounting | 1U rackmount (sliding rails incl.) |
Dimensions
Width x Depth x Height
|
438 x 483 x 44mm
17.24 x 19 x 1.75 inches
|
Weight |
8.3 kg / 18.29 lbs (unpacked)
13.1 kg / 28.88 lbs (packed)
|
